ISO Tolerance Calculator
Tolerance
Force (Static)
Two-Plane †
0.0 oz-in
0.0 oz-in
Equivalent Displacement
0.0 in
† Two plane tolerance is calculated assuming equal mass distribution along the axis of rotation (a symmetrical part) with the planes set equidistant from the center of mass.
ISO Grade Example Table (Tap to Select)(Click to Select)
| ISO Grade | Application |
|---|---|
| 0.4 | Spindles, High Precision Systems, Gyroscopes |
| 1.0 | Audio and Video Drives, Grinding Machine Drives |
| 2.5 | Computer Drives, Electric Motors and Generators, Compressors, Gas/Steam Turbines, Machine Tool Drives |
| 6.3 | Pump Impellers, Turbo-chargers, Fans, Flywheels, Electric Motors and Generators, Engine Components, Centrifuges, Gears, General Machinery, Water Turbines, Machine-tools,Aircraft Gas Turbines |
| 16 | Agricultural Machinery, Crankshaft Drives (inherently balanced, rigidly mounted) , Drive Shafts (cardan shafts, propeller shafts) |
| 40 | Cars Wheels, Car Wheel rims, Car Wheel sets, Car Drive Shafts, Crankshaft Drives(inherently balanced, elastically mounted) |
| 100 | Reciprocating engines, Large Crankshafts |
